پردازنده مرکزی
|
Intel® Celeron® J1900 (2M Cache, 2.0/2.42 GHz(Burst), 4 Cores), Fanless
|
|
حافظه داخلی
|
4GB Standard, DDR3L 1600 MT/s, Socket 1 x SODIMM
|
|
حافظه ذخیره سازی
|
SATA 2 (3Gb/s) 2.5 inch SSD 120GB, Support AHCI
|
|
سیستم عامل
|
Windows 7, Windows 8.1, Windows 10 IoT Enterprise, POS Ready 7
|
|
کارت صدا
|
Realtek ALC662-VD
|
|
صفحه نمایش
|
Type: 19.5″ TFT LED Backlight
Resolution: 1600 x900
Brightness: 250 cd/m² (typ.)
Touch Screen: Projected Capacitive Touch
|
|
تعداد پورت های USB
|
6 (Rear 2, Back 4, USB 2.0 x 6)
3 (Reserved for MSR, SCR, i-Button/Touch Controller/Camera), RJ-45
|
|
مشخصات پورت سریال
|
6 (COM 1 with 5V/12V Power Output on 9 Pins, BIOS)
(COM2~3 RJ-45 , Full Signal)
(COM5 Reserved for Cash Drawer Port)
(COM4 RJ-11, Only TX/RX, 12V Power Output, Reserved for 2×20 Customer Display)
(COM6 RJ-45, Only TX/RX, 5V Power Output, Reserved for MSR)
|
|
منبع تغذیه
|
Adaptor 12V, 5A
|
|
افزونه ها و امکانات مجزا
|
2nd Display: 9.7″, 12.1″, 15″ LCD Disply, 1024 x 768, , Optional Touchscreen
Customer Display: VFD, 20 Columns x 2 Lines
I/O Expansion:
1 x COM5 (RJ-45 8 Pins) (Factory Option)
1 x Cash Drawer Port (RJ-11 6 Pins) (Factory Option)
Storage: 2.5 inch SSD 128GB, HDD 500GB, 1TB
Magnetic Stripe Reader: Comply with ISO 7811, Support 1 & 2 & 3 Track
Smart Card Reader: EMV Level 1, 2 (TBD)
Dallas: Dallas i-button Reader (TBD)
Fingerprint: Yes
Wall Mount Kit: VESA-Compatible, 75 x 75(mm), 100 x 100(mm)
Serial Conversion Cable: RJ-45 to D-sub 9
Speaker: 2 x 1W (Stereo) (Factory Option)
|
|
نحوه ارتباط وای فای
|
USB to WiFi Module (Factory Option)
|
|
مشخصات ظاهری
|
Operating Temperature: 0 ℃ ~ 60 ℃ at 10% to 90% Humidity
Storage Temperature: -20 ℃ ~ 80 ℃ at 10% to 90% humidity, non-condensing
Dimensions (W x H x D): 490 x 337 x 210 (mm), 19.3 x 13.3 x 8.2(in)
Packing Dimension (W x H x D): 640 x 465 x 300 (mm), 25.2 x 18.3 x 11.8(in)
Net Weight: 9,000g, 19.8lbs
Packing Weight: 10,200g, 22.5lbs
Color: Matte Dark Grey, High Gloss White
|
|
گواهی نامه ها
|
CE, FCC, KC(TBD),CB(TBD),CCC(TBD)
|
|
برند
|
Posbank
|
