حافظه خارجی
|
SATA 3 (6Gb/s) 2.5 inch SSD 64GB (Max. 2 Optional), Support AHCI
|
|
برند
|
Posbank
|
|
پردازنده
|
Intel® Core™ i3
|
|
پورت سریال
|
6 (COM 1~2 with 5V/12V Power Output on 9 Pins, Jumper)
(COM3 with 5V/12V Power Output on 9 Pins, BIOS)
(COM4 RJ-11, Only TX/RX, 12V Power Output, Reserved for CDP)
(COM5 Reserved for Cash Drawer Port)
(COM6 RJ-45, Only TX/RX, 5V Power Output, Reserved for MSR)
|
|
سیستم عامل
|
Windows 10 IoT Enterprise
|
|
نمایشگر
|
Type: 15″ TFT LED Backlight
Resolution: 15″ 1024 x 768
Brightness: 15″ 300 cd/m² (typ.)
Touch Screen: Projected Capacitive Touch
|
|
درگاه های USB
|
6 (Rear 6 = USB 3.0 x 6)
|
|
درگاه های اتصال
|
Display: 1 x VGA (With Power Output)
PS/2 Port: 1 (Reserved for Keyboard or Mouse)
LAN:
1 x Gigabit Ethernet, RJ-45
Audio: 1 x Line-out, 1 x Mic-in
Power DC-IN:
1 x (4 Pin Connector)
|
|
کارت صدا
|
Realtek ALC 269
|
|
حافظه داخلی
|
4GB Standard (Max. 64GB), DDR4 2133MT/s, Socket 2 x SODIMM
|
|
منبع تغذیه
|
Adaptor 12V, 5A
|
|
مشخصات فیزیکی
|
Operating Temperature: 0 ℃ ~ 40 ℃ at 10% ~ 80% Humidity
Storage Temperature: -20℃ ~ 80℃ at 10% ~ 90% Humidity
Dimensions (W x H x D): 364 x 342 x 217(mm), 14.3 x 13.5 x 8.5(in)
Packing Dimension (W x H x D): 420 x 380 x 485(mm), 16.5 x 14.9 x 19.0(in)
Net Weight: 7,500g, 16.5lbs
Packing Weight: 9,500g, 20.9bs
Certification: CE, FCC, KC
Color: High Gloss Black, High Gloss White
|
|
امکانات مجزا
|
2nd Display: 9.7″, 12.1″, 15″ LCD Disply, 1024 x 768
Customer Display: VFD, 20 Columns x 2 Lines
I/O Expansion: 2 x USB 2.0 (Side) ㅣ 1 x Parallel Port (D-SUB 25 Pins) ㅣ 1 x Cash Drawer Port (RJ-11 6 Pins) (Factory Option)
Storage: 2.5 inch SSD 128GB, HDD 500GB, 1TB
Magnetic Stripe Reader: Comply with ISO 7811, Support 1 & 2 & 3 Track
Smart Card Reader: EMV Level 1, 2
Dallas: Dallas i-button Reader
|
